Product Introduction
A mobile tower trailer is a special vehicle that integrates a tower on a trailer chassis. This equipment is often used in situations where a temporary or movable tower is required, such as communications, monitoring, lighting, small lifting operations or temporary air traffic control.
Product Features
Compact Design
Even the tallest QT30 model has a retracted height of only 6.5 meters, while the smallest QT9 model has a retracted height of only 3 meters. This compact design greatly improves transportation efficiency, allowing the tower to easily pass through tunnels and bridges and travel on roads without special permits.
Large Load-bearing Capacity
The mobile tower trailer is made of high-strength aluminum alloy, which has a strength-to-weight ratio that is 3 times that of ordinary steel. As a result, all models have a maximum load capacity of 200kg, capable of installing multiple 4G/5G antennas (about 15kg each) or carrying a high-definition surveillance camera system weighing up to 80kg.
Safety Design
The mobile trailer tower is equipped with a full range of protective measures, including anti-slip pedals, safety guardrails and emergency descent devices. In addition, the hydraulic buffer system can control the tower descent speed in an emergency, ensuring the safe evacuation of personnel even in the event of a power outage.
Product Specifications
| model | QT9 | QT15 | QT20 | QT25 | QT30 |
|---|---|---|---|---|---|
| EXTEND HEIGHT | 9M | 15M | 20M | 25M | 30M |
| RETRACTED HEIGHT | 3M | 4M | 5M | 6M | 6.5M |
| MAX LOAD | 200kg | 200kg | 200kg | 200kg | 200kg |
| NO.SECTIONS | 4 | 5 | 5 | 6 | 7 |
| LIFT TYPE | winch | winch/hydraulic | hydraulic | hydraulic | hydraulic |
